Fearlessly Using JSON in MySQL

It will be discussed the benefits of using JSON in MySQL and why there’s no need to fear it. Especially for new developers, questions like these often come up when they first encounter JSON:

I can do a simple INSERT, but will I face issues with UPDATE?
How can I SEARCH within JSON?
Can I delete object X from a JSON node?
Can I UPDATE only object X and value Z under Y, without affecting everything else?
And more…

All will be tried to answer in the continuation of this article.

JSON

JSON Data Type

MySQL has supported the JSON data type since version 5.7.8 (with new features added in every version, some of which will be covered in this article from MySQL 8). JSON allows you to store documents more efficiently and functionally than the TEXT format used in previous versions.

It allows searching directly by keys or arrays within the JSON structure, making it extremely fast.

Storing data as JSON is roughly equivalent to storing LONGBLOB or LONGTEXT data.

You should only use the JSON data type if it’s really necessary, as it takes up storage space in the database.

Creating a Table with JSON

In a typical CREATE or ALTER query, simply adding a JSON column is enough. Since this is a well-known topic, I’ll skip over it quickly.

CREATE TABLE `settings` (
  `id` INT UNSIGNED NOT NULL AUTO_INCREMENT,
  `company_id` INT UNSIGNED NOT NULL,
  `config` JSON DEFAULT NULL,
  PRIMARY KEY (`id`)
);

When to Use It?

Imagine a data structure that multiple customers can customize, update, and use according to their preferences. If you need a structure that will be used frequently, you can do so using the JSON data type. For instance, think about the settings of a chat application with hundreds of parameters. Without JSON, you’d need to create individual fields for each, write migrations, and more. With JSON, you can achieve all this in seconds.

After adding JSON data to the database, you don’t need to worry about how to update, delete, or add keys. JSON functions allow you to handle this easily. Let’s now examine how these operations can be performed.

JSON Validation

Before adding JSON data to the table, you should validate it. JSON_VALID returns 1 if the structure is valid JSON and 0 if it’s not. Here’s a simple code block demonstrating this check:

SELECT JSON_VALID('{"color": "#1F71EA"}') AS Result;
+--------+
| Result |
+--------+
|      1 |
+--------+

Creating JSON Fields

Now that we have validated JSON data, let’s see how to add it to the database.

INSERT INTO `settings` (`company_id`, `config`)
VALUES (
  1,
  JSON_OBJECT("color", "#1F71EA", "background_color", "#FFFFFF", ...)
);
+----------------------------+
| Query 1 OK: 1 row affected  |
+----------------------------+

Adding JSON Data

There are multiple ways to create JSON data, depending on your needs. The functions below can be used in both INSERT and UPDATE queries. Their primary purpose is to help create a JSON set by adding variables directly, rather than manually constructing the JSON structure.

JSON_ARRAY

This function returns the values passed to it as a JSON array. Be cautious when using it: if you add multiple key/value pairs, only the first is preserved. Additionally, keys are sorted, and extra spaces between pairs are removed.

JSON_OBJECT

This returns the values passed to it as a JSON object. However, you can’t define a key as NULL when creating the object.

JSON_QUOTE

It takes a string value and returns it as a quoted JSON string. This is typically used to construct a JSON string for inclusion in another JSON structure.

SELECT JSON_ARRAY(1, "test", NULL, TRUE, CURTIME());
+---------------------------------------------+
| [1, "test", null, true, "11:30:24.000000"]  |
+---------------------------------------------+

SELECT JSON_OBJECT('id', 87, 'name', 'ufuk');
+-----------------------------------------+
| {"id": 87, "name": "ufuk"}              |
+-----------------------------------------+

SELECT JSON_QUOTE('A'), JSON_QUOTE("B"), JSON_QUOTE('"C"');
+-----------------+-----------------+-------------------+
| JSON_QUOTE('A') | JSON_QUOTE("B") | JSON_QUOTE('"C"')  |
+-----------------+-----------------+-------------------+
| "A"             | "B"             | "\"C\""            |
+-----------------+-----------------+-------------------+

JSON_TYPE

You can check the type of a JSON structure (ARRAY, OBJECT, scalar, etc.) using JSON_TYPE.

SELECT JSON_TYPE('[1, 2, "abc"]');
+-------+
| ARRAY |
+-------+

SELECT JSON_TYPE('{"a": 1, "b": 2}');
+--------+
| OBJECT |
+--------+

SELECT JSON_TYPE('{"a": 1, "b": 2');
+---------------+
| Query 1 ERROR |
+---------------+

Searching JSON Data

It’s possible to search for values within JSON. MySQL allows for searches similar to a LIKE query, with multiple search options available.

JSON_CONTAINS

This checks if a value exists within a JSON key and returns 1 or 0.

The path to the key uses the “$.” syntax.

JSON_SEARCH

This is similar to a LIKE query. It can use one or all parameters to specify whether all or just one condition must be met. It returns 1 for a match and 0 for no match.

JSON_EXTRACT

This allows you to specify key paths and conditions within JSON data. If desired, you can use it in a SELECT query to display values from JSON.

SELECT *
  FROM `settings`
  WHERE JSON_CONTAINS(config, '"#1F71EA"', '$.color');

SELECT *
  FROM `settings`
  WHERE JSON_SEARCH(config, 'one', '#FFFFFF') IS NOT NULL;

SELECT JSON_EXTRACT(config, '$.color') AS `Color`
  FROM `settings`;

Instead of using JSON_EXTRACT, you can use the shorthand -> operator introduced in MySQL 8.

SELECT company_id, config->"$.color" AS `Color`
  FROM `chat_settings`;

SELECT
  company_id, config->"$.general.background_color" AS `Color`
FROM `chat_settings`
WHERE
  config->"$.general" IS NOT NULL;

Updating JSON Data

You can use JSON_INSERT, JSON_REPLACE, and JSON_SET to update JSON values. These functions require a path index, denoted by $., to specify which part of the JSON object to update.

JSON_INSERT

This adds new key/value pairs to an existing JSON object.

JSON_REPLACE

This replaces existing key/value pairs. If the key exists, it is updated; otherwise, nothing happens.

JSON_SET

This combines INSERT and REPLACE by adding new key/value pairs if they don’t exist, or updating them if they do.

UPDATE `settings`
SET `config` = JSON_INSERT(
  `config`,
  '$.name',
  'Ufuk'
)
WHERE
  `id` = 1;

UPDATE `settings`
SET `config` = JSON_REPLACE(
    `config`,
    '$.general.name',
    'Ufuk Özcan'
)
WHERE
    `id` = 1;

UPDATE `settings`
SET `config` = JSON_SET(
    `config`,
    '$.general.surname',
    'Özcan'
)
WHERE
    `id` = 1;

Deleting JSON Data

To delete specific key/value pairs or rows using JSON data, you can use the following queries:

UPDATE `settings`
SET `config` = JSON_REMOVE(`config`, '$.name')
WHERE
  `id` = 1;

DELETE
FROM `chat_settings`
WHERE
  `id` = 42 AND
  JSON_EXTRACT(`config`, '$.name') = 'Ufuk' AND
  JSON_EXTRACT(`config`, '$.surname') = 'Özcan';

BONUS

For more information on additional JSON functions like JSON Table Functions, JSON Schema Validation, and JSON Utility Functions, check out the official MySQL documentation.
